In-line variable vacuum generators mod. VLR adjustable

In-line variable vacuum generators mod. VLR adjustable

In-line variable generators provided with great suction power. Thanks to their shape, since the aspiration and the air exhaust are on the same line and direction, these generators are particularly suitable for taking and transporting granulated, powders, liquids, vapors and fumes. Since no electrical connection is required, they can also be used in environments under the hazard of inflammability and they need virtually no maintenance.

In addition, thanks to their good suction flow, they can be used as a source of vacuum when removing and handling porous materials such as paper and textiles.

Art. A B C D E F H U P R
VLR250 6.5 19 32 94-105 22 32 5 G1/4 G1/8 G1/4
VLR375 10 25 45 155-165 38 45 5 G3/8 G3/8 G1/2
VLR500 13 32 51 155-160 38 51 5 G1/2 G3/8 G3/4
VLR750 19 38 58 175-189 38 51 5 G3/4 G1/2 G1



Art. Press. alim.*Press. alim.*Betr. druck* Consumo d'aria (l/min) ai differenti gradi di vuoto (-kPa)Air consumption (l/min) at different levels (-kPa)Luftverbrauch (l/min) bei den verschiedenen Vakuumgraden (-kPa)
  Bar 17 34 50 68 84
VLR250 5.5 112 169 233 276 342
VLR375 5.5 176 327 485 595 825
VLR500 5.5 340 625 795 940 1280
VLR750 5.5 650 875 1250 1790 2550



Art. Portata (l/min) ai differenti gradi di vuoto (-kPa)Vacuum flow (l/min) at different levels (-kPa)Durchsatz (l/min) bei den verschiedenen Vakuumgraden (-kPa)
  17 34 50 68 84
VLR250 280 240 200 162 125
VLR375 846 735 620 520 395
VLR500 1695 1325 1130 990 650
VLR750 3390 2460 1970 1440 1130
