Vacuum pumps with lubrication and oil separator cartridge G series - 90-105 mc/h

Vacuum pumps with lubrication and oil separator cartridge G series - 90-105 mc/h

Characteristics

Gamavuoto 90 to 105 m3/h lubricated vacuum pumps are characterized by a very simple design, by a strong, compact body and by a simple but efficient air cooling system. In the “G” series the electric motor is connected to the body of the pump through a flexible connector and this allows the use of different kinds of motors (DC power, ADPE, ATEX, and so on…) and there is also an oil separator filter cartridge an interchangeable oil separator filter cartridge placed on the exhaust that helps to reduce practically to zero smoke emissions.

They require only the bare minimum of maintenance since the recycling lubrication allows the oil to be changed or topped up only according to the actual operating times.

Installation

Connect up the vacuum circuit. Set up the electrical connections to the motor and check that the pump is rotating in the right direction

WARNING! If the electrical motor rotates in the wrong direction, the suction unit could be damaged.

Art. Volume aspiratoVacuum flow Press. finaleFinal pressure ABS VelocitàRpm Potenza motoreMotor power PesoWeight A B C D E F G I Viscosità olioOil viscosity
50 Hz
Mc/h
60 Hz
Mc/h
mbar/ass 50 Hz
g/min
60 Hz
g/min
50 Hz
Kw
60 Hz
Kw
kg
GPOL 105/GD 105 126 40 1450 1700 3 3.6 90 210 410 415 680 185 420 1-1/2" 12.5  ISO 150
