Standard suction-cup holders with valve and fi xing screw

This type of suction-cup holder has the same characteristics as the standard type, with the addition of a valve which is activated only when a pressure is exerted on the suction cup, and closes automatically when the pressure is released.

N.B. - This type of suction-cup holders is particularly recommended for avoiding vacuum leaks, or when using a more powerful pump.

  • Rapid straight and “L” shaped joint
  • Plastic tube diameter 6 x 8
  • Rapid “L” shaped joints = art PSV........L
Standard suction-cup holders with valve and fi xing screw
PSV_35L
Art. A B D L c 25 L c55 L c80 Vite di fiss.Fixing screwBef. schr.
▲ PSV 35/L 17 51 35 165 207 237 SUM 9
▲ PSV 45/C 17 51 45 165 207 237 SUM 14
▲ PSV 45/L 20 51 45 168 210 240 SUM 14
▲ PSV 60 22 51 59 170 212 242 SUM 21
▲ PSV 65 24 51 65 172 214 244 SUM 21
● PSV 87 40 44.5 87 181.5 223.5 253.5 SUM 21



NB: the suction cups are supplied on request, specifying the material
