Single-stage vacuum generator mod. EVM3 SG
Single-stage vacuum generator mod. EVM3 SG
Used particularly for suction from one or more working areas, attached directly to one or more suction cups.
| CaratteristicheTechnical detailsEigenschaften | U. MisuraUnit of measurementMaßeinheit | EVM3 SG | EVM3 SG 1/2 |
|---|---|---|---|
| Pressione d’esercizioWorking pressureBetriebsdruck | Bar | 5 | 5 |
| Vuoto maxMax vacuumMax. Vakuum | -kPa | 91.2 | 91.2 |
| Attacco aspirazione (U)Suction cup attachment (U)Absauganschluss (U) | 1/2" gas | 1/2" gas | |
| Alimentazione aria compressa (P)Air compressed attachment (P)Druckluft-Versorgung (P) | 1/4" gas | 1/4" gas | |
| Scarico aria (R)Exhaust air attachment (R)Luft-Auslass (R) | 3/8" gas | 1/2" gas | |
| Posizione di montaggioMounting positionMontageposition | indifferentemakes no differencebeliebig | indifferentemakes no differencebeliebig | |
| Consumo d’aria a 3 BarAir consumption at 3 barLuftverbrauch bei 3 Bar | NI/min | 280 | 280 |
| Portata (aspirazione) a 3.5 BarVacuum flow at 3.5 barDurchsatz (Absaugung) bei 3.5 Bar | NI/min | 190 | 190 |
| PesoWeightGewicht | kg | 0.523 | 0.519 |
