Vacuum cylinders Mod. CV 3025
Vacuum cylinders Mod. CV 3025
Mini cylinder serviceable by the vacuum bore 30 mm and stroke 25 mm simple effect pushing with mechanical return spring by removing power of the vacuum. Maintaining vacuum in the power supply and closing the passage in the rod using a suction cup fixed on the head of same, at the time of grip, the rod will return into position thanks to the combination vacuum / spring until vacuum is interrupted and consequently the suctioncup can be detached, thus returning to the initial condition. Made in antirotation version, allows the use of oval and / or rectangular suction cups maintaining the position.
| CorsaStrokeHub mm | 25 |
|---|---|
| Forza di spinta a -KPa 80 kgThrusting force at -KPa 80 kgSchubkraft bei -KPa 80 kg | 4.3 |
| Forza di sollevamento a -KPa 80 kgLifting force at -KPa 80 kgHubkraft bei -KPa 80 kg | 1.0 |
| Grado di vuoto minimo -KPaMin. vacuum level -KPaMindest-Vakuumgrad -KPa | 60 |
| Portata necessaria minimaMin. capacity necessaryNotwendiger Mindestdurchsatz Nl/min | 30 |
| Temperatura di esercizioWorking temperatureBetriebstemperatur °C | 5 ÷ 80 |
| PesoWeightGewicht g | 145 |
