Pneumatic vacuum switch

Pneumatic vacuum switch

Adjustable pneumatic vacuum switch, which thanks to a 2-way micro valve permits the opening or closing of a pneumatic passage. Particularly suitable for use with vacuum generators with compressed air for power management depending on the set vacuum.

  Art. SVC/LP Art. SVC/LPA
Campo di regolazioneAdjustment rangeVerstellbereich mbar ass. 930 ÷ 50 900 ÷ 40
Differenziale fissoFixed differentialFestes Differential mbar 70 100
RipetibilitàRepeatabilityWiederholbarkeit mbar ±5 ±5
Segnale a riposoIdle signalRuhesignal NC NO
Pressione di alimentazioneWorking pressureVersorgungsdruck bar 2 ÷ 8 2 ÷ 8
Portata max della microvalvola a 6 barMax. capacity of 6 bar microvalveMax. Durchsatz Mikroventil bei 6 bar NI/min 72 72
Temperatura di lavoroWorking temperatureArbeitstemperatur °C -10 ÷ +60 -10 ÷ +60
PesoWeightGewicht g 104 102
