Vacuum regulator RTN
Vacuum regulator RTN
This regulator, built in aluminum anodized, it is able to regulate the vacuum and the flow in a fine and precise way to use.
The vacuum degree and the flow vary in a directly proportional way.
Operation
Membrane-piston reducer.
Working pressure from -0,04 to -1 bar, with a capacity of up to 50mc/h.
Working temperature from +10°C to +70°c.
| Art. | A | B | C | D | E | F | Gø | H | Iø |
|---|---|---|---|---|---|---|---|---|---|
| RTN 3/4" | 50 | 80 | 60 | 40 | 20 | 28.5 | 3/4" | 85 | 8.5 |
| RTN 1” | 60 | 98 | 60 | 40 | 15 | 28.5 | 1" | 85 | 8.5 |
